Designed for multipurpose use

Mobile testing often requires a variety of testing systems. FOERSTER’s versatile new TCM serves as a unifying platform for established eddy current testing products. Deep-penetrating low frequency (LF) testing with DEFECTOSCOP for measuring residual wall thickness and high frequency (HF) testing with DEFECTOMETER for detection of the smallest cracks are now integrated in a single device.

The TCM platform also covers conductivity measurement of non-ferromagnetic materials. The intuitive touch interface allows the user to select the individual tasks via corresponding apps. Automatic probe recognition helps you set the optimal test and measurement parameters to achieve the best possible results.



 YouTube Playlist





 Software modules available

  • DEFECTOSCOP: universal eddy current testing with rotating, HF and LF probes.
  • SIGMATEST: measures electrical conductivity of non-ferromagnetic metals.
  • ECA (Eddy Current Array): eddy current testing via sensor arrays with up to 512 channels

Technical Data

Display:8.0“ touchscreen, 1280 x 800, 800 nits, readable in sunlight
Switch between usage with finger or gloves
Protection:IP 66, 1.5 m drop height
Weight:1.3 kg
Dimension:227 mm x 150 mm x 51 mm (L x W x H))
Temperature:-20 °C to +50 °C
Power:Battery time: 6h
Camera:Back camera with 8.0 MP, front camera with 2.0 MP
Storage:128 GB SSD
Connection ports:19-pin LEMO, Thunderbolt 4, USB 3.2 Gen2 (type C), microSD reader
Audio:Audio in/out (combo jack)
Documentation:Save/export raw data, screenshots, reports
Embedded Help:Find information on every setup and dialog for fast and save usage
Languages:English, German, Spanish, Japanese, Chinese, Czech, Italian, French
